Description

Fault Finding is an easy learning platform that is very helpful for students to understand the use of a thyristor

in intensity control. With this platform’s internal power supply, two firing methods are available The

attenuator is a part for observing high voltage signals on an oscilloscope. This platform is provided with

internal AC/DC power supplies and comprehensive study material. This kit helps students to learn to find the

fault in the circuit.

Features

Switch for selection of firing circuit

Gradual firing angle control up to 180 degree

Switch for selection of firing circuit

Technical Specification

On board firing circuits:

DIAC TRIAC firing circuit

UJT firing circuit

SCR & TRIAC : 1 SCRs TYN 616, 600V/16A and TRIAC BT136

Load : Lamp 100W

Mains Supply (mains) : 220V/110V, 50 Hz/60 Hz

leaning & teaching content

Features of the Learning Platform

Courses

Documentation

Tracking

Software

Management

e-learning

System

Note: Learning software : Software/Web based leaning platform

Component libraries

Build and Test Circuit

Capable of building and testing DIAC TRIAC firing circuit, UJT firing circuit

Hardware Description

Learning & teaching content modules

DIAC

TRAIC

DIAC Firing circuit

TRIAC Firing circuit

UJT firing circuit

Circuit Analysis

Note: Photos are only indicative and are subject to change with specifications. Specifications and Photos can be altered without prior notice in our constant efforts for improvement
