Description

OBJECTIVES:

This System is to ensure precise, stable and efficient control of fluid levels and temperature in industrial processes or systems.

Keep fluid levels and temperature within predefined ranges or setpoints to ensure process stability and safety.

Optimize the control of fluid levels and temperatures to ensure efficient use of energy and resources, minimizing waste and operational costs.

Implement automated control using a feedback loop as with PLC controllers to continuously monitor and adjust the process in response to changes in input or environmental conditions.

Minimize the difference between actual and desired levels or temperatures by quickly responding to system disturbances, such as sudden inflow changes or temperature fluctuations.

COMPONENTS:

Sump/water storage tank

Temperature Tank

Temperature Heater/ Geyser

Rotary selector switch

CPVC Piping

Centrifugal Pump

Level switch

Temperature transmitter

Pneumatic Control valve

Heater Control card

Rotameter

E/P Converter

A.F.R / F.R.L Unit

Power Supply

Electronics PIC Controller

Electrical Control Panel

SCADA Application Software

Air Compressor

SPECIFICATIONS:

Understand the concept of feedback Level & Temperature control loop.

User Friendly, Self Explanatory Systems.

Leak proof Safety Measures, sturdy piping.

Enhanced Electrical Safety Considerations.

Training Manual & Mimic Charts for Operation Ease.

System Frame with Caster Wheel Arrangement for ease in movement.

M.S. powder coated cubical plant with standard Instrument Mountings.

Inbuilt Safety Measure to avoid improper usage.
