Description

On Board

Based on 8051/89C52 Microcontroller with LCD Display, USB

Interface, ADC, DAC & Inbuilt Power Supply

On board 32K RAM

Battery backup for RAM area

64 K bytes of EPROM with powerful monitor program

Total memory expandable upto 256K Bytes using four 28 pin

sockets

3 channel programmable timer/counter using 8253

IBM PC compatible keyboard

20 x 2 LCD display for standard model

48 I/O lines

Onboard Analog to Digital converter using ADC0809

Onboard Digital to Analog converter using DAC0800

Onboard Real Time Clock

IBM PC keyboard

LCD Display

Crystal Frequency: standard frequency

DC Power Supplies +12V, -12V, +5V & – 5V

Programming mode: Hex keypad mode, PC mode, USB

Communication
